11
Technical data and dimension sheets
Technical data
Operating Instructions – MOVIMOT
®
flexible
312
11.3.11 Technical data of encoder options /AZ1Z
Encoder option Single-turn resolution
(Position resolution per
motor revolution)
Multi-turn resolution
(Max. counter for complete
motor revolutions)
Interface
connection:
/AZ1Z
Multiturn absolute encoder
12bits 4096inc. 16bits 32767
-32768
MOVILINK
®
DDI, coaxial
11.3.12 Technical data of the CBG.. keypads
Keypad CBG11A CBG21A
Part number 28232646 28238133
Interfaces D‑sub, 9‑pin, female (CAN interface)
USB 2.0 mini B, female (PC connection)
Operating temperature 0 to 60°C
Degree of protection IP40 according to EN60529
Dimensions H × W × D 100 × 45 × 20mm 110 × 65 × 20mm
Display size H × W 23 × 28.5mm 37 × 49mm
Screen diagonal 1.5" (38mm) 2.4" (61mm)
Display resolution H × W 64 × 78 pixels 240 × 320 pixels
29129451/EN – 12/2019
