Electrical installation
Installation instructions
Operating Instructions – MOVIMOT
®
flexible
51
5.3.4 Activating line terminals X1
Adhere to the following sequence when you activate the line terminalsX1:
Line terminals X1 (the following figure shows a schematic illustration)
2.
1.
25649924107
5.3.5 Activating terminals X2_A for motor, brake and temperature sensor
Adhere to the following sequence when you activate the terminals X2_A for motor,
brake and temperature sensor:
Terminals X2_A for motor, brake and temperature sensor (the following figure
shows a schematic illustration)
2.
1.
9007225066726923
