Sharp DX-C200 - Cleaning the Toner Density Sensor

Cleaning the Toner Density Sensor
Clean the machine when the error message instructing you to do so appears.
This procedure explains how to clean the toner density sensor of the yellow print cartridge as an
example of how to clean a sensor.
• The inside of this machine becomes very hot. Do not touch the parts labeled " " (indicating a
hot surface).
1. Pull up the lever on the top cover, and then carefully raise the top cover.
Make sure that the ADF is closed.
CES138
2. Lift out the rearmost print cartridge.
CES086
10. Maintenance
402
