1-71
BEFORE USING THE MACHINE►LOADING PAPER
Loading tab paper into tray 4
1
Remove the tab paper guide.
The guide is stored inside tray 4.
2
Pull out the tray and install the guide.
Adjust the guide plates to the triangle mark position.
Install the guide so that it may cover the guide plates.
Adjust the guide plates in the tray to match the longitudinal
and transversal dimensions of the paper to be loaded.
3
Insert the tab paper into the tray.
Place the tab paper with the print side facing down so that
the tab is to the left.
To Next Page
