Shimadzu CTO-40C CL User Manual

n CMD (Column Management Device)
The device stores information on a column and is capable of managing the column in
combination with the database of a PC workstation. One CMD chip is required for each
column. For details, refer to the instruction manual of LabSolutions chromatography data
system.
System Guide "3.9 Column Management"
Option Part No. Features
CMD (Column
Management Device)
228-37281-41
The device is stored colmun-related infomation.
One CMD chip is required for each column.
CMD cable (150 mm) 228-39991
The cable connects a CMD chip with the
instrument.
CMD cable (400 mm) 228-39991-01
n Automatic column switch valve
Two valves can be installed with one on the lower-left part and the other on the
lower-right part.
Option Part No. Features
FCV-0206H 228-65607-58
The valve with two positions and six ports
automatically switches between two columns.
The withstand pressure is 80 MPa.
FCV-0206H3 228-65624-58
The valve with two positions and six ports
automatically switches between two columns.
The withstand pressure is 130 MPa.
FCV-0607H 228-65608-58
The valve with six positions and seven ports
automatically switches between six columns.
The withstand pressure is 80 MPa.
FCV-0607H3 228-65625-58
The valve with six positions and seven ports
automatically switches between six columns.
The withstand pressure is 130 MPa.
FCV-DR 228-65602-58
The unit drives the previously listed valves. (One
unit is required for each valve.)
FCV-36AH 228-45206-58
The valve with two positions and ten ports
automatically switches between two columns.
The withstand pressure is 100 MPa. (Including
the driving unit)
Manifold 228-72436-41
The part joins tubes of column outlets to
enable one valve to switch between columns.
PEEK resin is used for a wetted part.
Safety GuidelineSystem Guide "5.
Precautions for Mobile Phase Selection
and Use"
FCV installation kit
(CTO-40C)
228-72589-41
The common installation kit is required for
installing the previously listed valves in the
instrument. (Only one unit is required for this
instrument.)
FCV tubing two-piece kit
(ID 0.3)
228-72437-41
The tubing kit is required for installing two
columns.
CTO-40C CL
3
1.3 Optional Parts
1
