n Validation support information group [VALIDATION]
Name Function Ref.
DATE Displays and sets the date. P.35
TIME Displays and sets the time. P.36
MEMORY CHECK Runs the memory (ROM/RAM) check. P.36
LEAK SENSOR CHECK Runs the leak sensor check. P.36
GAS SENSOR CHECK Runs the gas sensor check. P.37
TEMPERATURE CHECK
Checks the precision and accuracy of temperature
control.
P.37
n Calibration support information group [CALIBRATION]
Name Function Ref.
Input PASSWORD
*1
Input a password. P.38
OPERATION MODE Not used in CL model. -
DATE FORMAT Changes the displayed order of year, month and day. P.38
INITIALIZE PARAM Initializes parameters. P.39
PARAMETER LOCK Prohibits change of parameters. P.39
PARTS MGMT TOOL Sets the usage of the parts management tool. P.39
PASSWORD SETTING Changes the password. P.39
LEAK THOLD Not used in CL model. -
GAS SENS CALIB Not used in CL model. -
TEMP1 CALIB Not used in CL model. -
TEMP2 CALIB Not used in CL model. -
VALVE1 ROTOR
VALVE2 ROTOR
Sets the estimated replacement time of the rotor seals
of the automatic column switch valves installed.
P.41
VALVE1 STATOR
VALVE2 STATOR
Sets the estimated replacement time of the stator seals
of the automatic column switch valves installed.
P.41
*1
In the calibration support group, an invalid password prevents the user from going further than
[OPERATION MODE] even if the user presses [Enter].
3.5.2
Product Information Group (PRODUCT INFO)
The group is relevant to information of the instrument.
n Displaying the serial number《SERIAL NUMBER》
Displays the serial number of the
instrument.
32
CTO-40C CL
3 Operation
