n Optional Parts
Parts Name
Inspection/
Maintenance Item
Maintence Timing Remark
FCV-0206H
Valve rotor/stator
replacement
Replace after
approximately 50,000
cycles of use.
*1
Contact your
Shimadzu
representative.
FCV-0206H3
Replace the valve rotor
after approximately
10,000 cycles of use.
*1
Replace the valve stator
after approximately
20,000 cycles of use.
*1
FCV-0607H
Replace after
approximately 25,000
cycles of use.
*1
FCV-0607H3
Replace the valve rotor
after approximately 5,000
cycles of use.
*1
* Replace the valve stator
after approximately
10,000 cycles of use.
*1
FCV-36AH
Valve head assy
replacement
2 Years
*2
Contact your
Shimadzu
representative.
*1
Only when mixed solution of water and organic solvent is used. The lifetime may be extended or
shortened depending on the type of delivered solvent and the delivery pressure. The use of a
solvent such as chloroform and THF as the mobile phase or the continuous delivery of pure water
with 80 % or higher concentrations at a high pressure may shorten the lifetime. Long time storage
of the instrument after the use of a buffer solution that dries and leaves crystals and insoluble
matter as the mobile phase may extremely shorten the lifetime of the rotor. Thoroughly rinse the
flow lines with distilled water or deionized water.
*2 Replace at 10,000 revolutions.
4.1.3
Check After Inspection and Maintenance
After inspection and maintenance, check any leakage during pumping.
When
the parts management tool （PARTS MGMT TOOL） is not used, input the
part number when replacing a part not registered in the PARTS MGMT TOOL.
"Inputting a replacement part number《PART REPLACEMENT》" P.34
4.2 Temperature Accuracy Calibration
Re-calibration is required if the temperature accuracy of [TEMPERATURE CHECK] fails the
temperature control function test of the component validation.
"Checking the temperature control accuracy
《TEMPERATURE CHECK》" P.37
56
CTO-40C CL
4 Maintenance
