2.2 Interior
No. Name Function
1 Column bracket Used for fixing columns.
2 Tube cap Removing the caps allows inserting tubes.
3 Optional hole cap
Used for installation of an optional active preheater
and multi-column rack.
4 [CMD4/Mixer] connector
The connector is for a mixer detection device
(optional). ([CMD4] is a future expanded function.)
5
Automatic column switch
valve (optional) installation
part
Allows installation of the optional automatic column
switch valves.
6 Column clamp Used for fixing tubes.
7 Thermosensor The sensor is for temperature measurement.
8 Gas sensor The sensor detects organic solvent vapors.
9 Liquid leak sensor The sensor detects leakage of aqueous solvent.
10 [CMD1] connector
The connector is for a column management device
(CMD) (optional).
8
CTO-40C CL
2 Parts Identification and Function
