1.2 Component Parts
This instrument consists of the standard parts listed below. Check the parts against this
list after unpacking.
No. Part Name Part No. Q'ty Remark
- Main Unit CTO-40C CL - 1 -
-
Safety Guideline
(Booklet)
228-97195 1
Contains cautions for use
regarding the instrument.
-
Instruction Manual/
System Guide
(CD-ROM)
228-97193-41 1
1 Filter holder 228-72234 1
System Guide "7
Installation"
2 Air filter 228-72570-01 1
3 Drain Tube 228-25162-03 1
4 Rubber column clamp 228-72586 2
5 Clamp CKN-10-R 072-60330-53 1
6 Clamp DKN-10GSP 072-60319-01 1
1.3 Optional Parts
Optional parts which can be added to the column oven are listed below.
For information about other optional units listed below, contact your Shimadzu
representative.
For optional parts for the whole LC system, refer to System Guide. For columns, refer to
Shimadzu's column catalog.
n Parts for the oven
Option
Part No. Features
Active preheater 228-72084-41
The preheating unit heats the mobile phase
before it enters columns by independent
heating control. The unit controls the
temperature gradient in columns so that sharp
peaks are obtained.
Column clamp B5 228-15617-41
Can fix one column with an outer diameter of
6.5 mm to 9.5 mm. (Metal)
Column clamp B8 228-15617-42
Can fix one column with an outer diameter of
9.5 mm to 12.7 mm. (Metal)
Column catch 228-28637-91
Can fix two columns with an outer diameter of
6.5 mm to 12.7 mm. (Metal)
Remote Cable 228-28253-91 Used for connection of an external device.
2
CTO-40C CL
1 Overview
