n Displaying the number of uses of the stator seals of the automatic column switch valves
《VALVE1 STATOR USED》《VALVE2 STATOR USED》
If the Parts Management Tool is used, users cannot reset the number of uses
with the operation panel. Reset it through the tool. If you wish to manage the
data directly with the instrument without using Parts Utility, some settings need
changing.
"Setting the usage of parts management tool《PARTS MGMT TOOL》" P.39
Displays the number of uses and estimated
replacement time of the stator seals of the
automatic column switch valves installed.
After replacing the stator of a valve, press
[del]. This resets the number of uses to "0" and then the reset date is recorded in a
maintenance log.
[VALVE1] indicates the valve installed on the left part of the instrument and [VALVE2] the
one installed on the right part.
When an automatic column switch valve is not installed, the panel does not display the
corresponding data.
For a valve for LC-30A series or earlier (FCV-xxAH), the number of uses of the stator seals
can not be managed by users and not displayed on the display panel.
n Inputting a replacement part number《PART REPLACEMENT》
If the Parts Management Tool is used, users cannot input a part number with
the operation panel. Use Parts Utility. If you wish to manage the data directly
with the instrument without using Parts Utility, some settings need changing.
"Setting the usage of parts management tool《PARTS MGMT TOOL》" P.39
Input a part number when replacing a
general part.
Pressing [Enter] and inputting a part
number with the numeric keypad saves the
data in a maintenance log.
n Displaying the maintenance log《MAINTENANCE LOG》
Displays twenty records of previously
replaced parts with the dates of their
replacement.
After pressing [→], press [↓] several times
to display the replaced parts in order.
The example indicates that the rotor seal
of the automatic column switch valve 1 was replaced on May 12, 2018.
34
CTO-40C CL
3 Operation
