１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - ７
CXDI-50G
CXDI-50G is containing mainly three componets;
Imaging unit; Digital Cassette that has the mobility and can be used on the optional angles
Power box; Power supply and data gateway for imaging unit mounted in the MUX-100D.
CXDI ; Digital Radiography Operation System for CXDI-50G, installed in Control PC and controled with Touch panel
monitor on the MUX-100D.
(1) Imaging Unit
The sensor unit converts the X-ray image to the electrical signal (O/E Conversion) and after performs the A/D conversion,
transfer its signal through the Power Box with Ethernet cable to the Control PC.
Imaging unit
Effective range 353 x 430 mm
Number of Pixels 2214 x 2700
Effective Number of Pixels 2208 x2688
Pixel Pitch 160µm x 160µm
Fluorescent substance GOS Fluorescent screen
Imaging Unit mass 4.8kg (except Grid)
Mechanical strength Load uniformly: 150kg
Load partly: 100kg/
φ
40mm
Mass 4.8 kg (Except cable)
Attenuation equivalent of front panel 0.2mmAl.Eq.
Dimension 491(W) x 477(D) x 23(H)mm with operation grip
Power Box
Communication interface standard IEEEE 802.3u (100BASE-TX)
Connector type: RJ45
Dimension 358(W) x 200(D) x 65(H)mm
CXDI
Image field sensing Automatic field sensing
Grayscale 12bit (4,096 grayscale)
Preview image access time Approx. 3 second
Data output DICOM 3.0 compatible, Print Management Service Class (SCU), Storage
Service Class (SCU) (JPEG transfer syntax available)
Storage Temporary storage in Hard disk of the Control PC
Option
Grid Attenuation equivalent:2.3mmAl.Eq.
For detail about CXDI, please refer to CXDI series operation manual (Canon CXDI Digital Radiography).
