１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - ６
Minimum specific filtration
Total 2.5 mm Al 70 kV
X-ray tube assembly Equivalent to 1.5 mm Al 70 kV
Multi-leaf collimator Equivalent to 1.0 mm Al 70 kV
Classification of the system
Method of protection against electric shock
ClassⅠ (only during charging)
Internal powered (during powered by internal battery)
Degree of protection against electric shock
Type-B
Classification according to operation mode Continuous operation with intermittent load
*For detail about X-ray-tube assembly, please refer to X-ray tube operation manual (M535-E219).
Options
MUX-100D MUX-100DJ
Remote controller
Infrared type
Ready operation, X-ray operation, Collimator lamp ON/OFF
Removable X-ray protective screen Removable X-ray protective acrylic screen
Dose Area Meter Indicates the dose area.
Grid Refer to CXDI manual
NOTE: Special option can not be changed after the equipment being shipped.
