１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - ５
MUX-100D MUX-100DJ
Collimator
R-20C
Shape Rectangular
Max. field 430 × 430 mm SID 1m
Field
Min. field 0 × 0mm (leaves overlapped)
Average illumination > 160 lx
Contrast ratio of edge > 3
Accuracy
2％ of SID
Display of center Cross lines
Type of lamp Halogen lamp (12V, 100W), #55939
Light field
Illuminating period 30 seconds, with automatic turn-off time switch
SID indicated 1, 1.5, 2 m
Dimensions indicated 20(8), 23(9), 25(10), 28(11), 30(12), 36(14), 43(17) cm(in.)
Field size indication
Accuracy of SID indication 5%
Drive of leaves
manual
Mounting dimension (Focus to fit surface distance)
56 mm
External dimension (W × D × H)
202 × 211 × 197 mm
X-ray tube Assembly*
Model Name 0.7U163CS-36
Spot size 0.7mm
Target angle 16deg
Nominal X-ray tube
Voltage
Radiography 125kV
X-ray tube
Assembly
Max. Heat 750kJ(1060kHU)
Max. Continuous heat dissipation
rate
120W(170HU/s)
X-ray Tube Max. Anode heat dissipation rate 212kJ(300kHU)
Max. Anode heat dissipation rate 800W(1130HU/s)
Max. Continuous heat dissipation
rate
210W(300HU/s)
Weight 13kg
Battery
Type Small sized value regulated lead-acid battery
Specification 12V
Quantity 20 pieces
To Next Page
