６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - ３４
Rear view of the unit
(a) (b) (c)
Fig. 6-52 How to remove FPD box and DR assy
7. As shown in Fig. 6-53, detach the cable cover for DC motors.
Fig. 6-53 Remove Cable Covers for DC motors
Fixing Plate
Cable cover
