Shimadzu MOBILE DaRt MUX-100D Series User Manual

3
7-2.4 F03
(detected by hardware)
The -15V power supply for the control circuit is abnormal.
Check -15V at CP
on X CONT.
X CONT or NEXSC is
abnormal.
→ Replace them in turn.
Check output
of power supply
PS1.
PS1 is abnormal.
→ Replace it.
-15V may be short-
circuited with GND on X
CONT or other PCB.
Normal
Normal
Abnormal
Abnormal
7-2.5 F11 (KV OVER)
(detected by software, at 20ms after exposure and each 100ms )
The measured tube voltage is higher by approximately 30 kV or more than the preset value.
Measure CP9 (TKV),
CP12 (RKV),CP11(TMA),
CP13(RMA) on X CONT.
RKV ,RMA abnormal?
X CONT or NEXSC is
abnormal.
→Replace them in turn.
① X CONT,
② X-RAY tube
③ High voltage transformer
may be defective.
abnormal
normal
abnormal
Readjust FVR
