C
)
4
7-2.6 F12 (KV UNDER)
The measured tube voltage is lower by 50% or more than the preset value (
detected by software, at 20ms
after exposure and at each 100ms )
NOTE) Most probabily that glow discharge has occurred in the X-ray tube.
When checking the IGBT gate waveform, take proper action such as short-circuiting to prevent generation of
high voltage in accordance with Appendix C in the Installation Manual.
Check CP9 (TKV)
and CP12 (RKV) on
X CONT.
RKV abnormal?
Or both normal?
Perform adjustment
related to tube voltage
shown in Appendix C in
Installation Manual.
Readjust FVR
YES
NO
Waveform
at CP29 (F), CP33
(A/D) or CP34 (B/C)
normal?
X CONT is abnormal.
→Replace it.
X CONT or NEXSC is
abnormal.
→Replace them in turn.
Only either
KVFB+ or KVFB-
output?
YES
NO
One side of high voltage
transformer is defective.
→Replace high voltage
transformer.
IGBT
gate waveform on
INVERTER UNIT
normal?
INVERTER UNIT is
abnormal.
→Replace it.
①Xraytube
② High voltage transformer
③High voltage cable
may be defective.
If FVR does not become normal, proceed to next step.
If does not become normal, proceed to next step.
Abnormal
Normal
Normal
To Next Page
