４ INSTALLATION AND MAINTENANCE/INSPECTION
ＭＵＸ-１００ SERVICE MANUAL ４ - ２０
11. Set CXDI-50G referring to “CXDI-50G Service Manual”.
(1)Network Settings
(2)Linearity check of Transfer Image Density.
(3)Operation Unit Gamma correction.
(4)FD Backup of data that sets backup when it is set.
(5)Calibration
・ The exposure condition of the calibration is aprox. 60kV, and 2mAs at the exposure
distance (SID) 1m.
・ The calibration error might occur because of differences the exposure distance (SID)
and the X-ray back scatter etc. When the calibration error occurs, the error screen is
displayed in the touch panel monitor. Check the content of the error, and change the
calibration condition (exposure conditions of MUX). % is displayed to the average of
dose product. Lower the calibration condition when the displayed value is large.
Raise the calibration condition when the displayed value is small.
・ Set to the exposure condition used for the calibration from the touch panel monitor to
CXDI-50G when the calibration ends. (In a self-diagnosis and the next calibration,
the set exposure condition is displayed in the touch panel monitor as a reference
exposure condition. )
(6)Self Test
・ Self-test condition is the same as calibration condition.
12. Attach the cover.
