４ INSTALLATION AND MAINTENANCE/INSPECTION
ＭＵＸ-１００ SERVICE MANUAL ４ - ２２
４ -2- 11 Attachment of screw caps
At last , attaching the screw caps in the screw holes of each covers.
Side Cover: 4pieces on each sides Collimator: 2pieces
FPD BOX：6 pieces
Top Cover: 3pieces Cable Cover: 4pieces
Front Cover 4pieces，Front Rear Cover2pieces， Arm Cover 6pieces
Column Cover 4pieces Total:10 pieces Middle Arm 2pieces
Fig. 4-25 Attaching the requiring caps
