４ INSTALLATION AND MAINTENANCE/INSPECTION
ＭＵＸ-１００ SERVICE MANUAL ４ - ２３
４-3 Maintenance/inspection Procedure ･･･････････････････････････････････････････････････････････････
４-3-１ Flow chart in maintenance/inspection procedure
When perform maintenance/inspection of the MUX-100D series , follow the flow chart below.
Fig. 4-26 Flow Chart in Maintenance/Inspection Procedure
４-3-２ Confirmation of daily inspection by user
Table 4-9 shows the daily inspection items requested to the user in the instruction manual. Ask the user whether the
user is performing daily inspection. Check the daily inspection items upon necessity.
Item Check point Remark
Appearance Any damage (physical damage) to the cover?
Wheels and their
surroundings
Any abnormal vibrations or sounds occurring while
driving the unit.
Any physical damage to the front wheels?
Driving handle Any unusual looseness?
X-ray Tube Support
stand
Any abnormal sound occurring during rotation or
signs of physical misalignment or damage?
Tube arm Any scratches or abnormal sounds occurring during
up/down movement and expansion/ contraction?
Can the tube arm couple to the locking section
without undue stress?
Catch Section Is the top plate loose? Does it rattle or make noise?
Arm catch Any unusual looseness?
X-ray Tube holder Any loose parts?
Collimator and its
attachments
Are the collimator and handle bars fixed correctly?
X-ray control panel Any flicker or abnormal display?
HT Cables and other
cables
Any twisting or physical damage of the outer
insulation?
Counterbalance Wire 1) Any strand of the rope frayed or damaged? Refer to
Periodical
Start
Periodical inspection
End
Confirmation of daily
inspection by user
Cleaning
Perform confirmation while referring to 4-3-2.
Perform cleaning while referring to 4-3-4.
Perform periodical inspection while referring to 4-3-3.
To Next Page
