４ INSTALLATION AND MAINTENANCE/INSPECTION
ＭＵＸ-１００ SERVICE MANUAL ４ - ２５
４-3-３ Periodical inspection
CAUTION
The special serviceman who received education surely needs to carry out a scheduled inspection.
When performing the periodical inspection upon request from the customer, follow the items shown in Table 4-10.
For inspection, covers should be removed. Remove them while referring to 6-1.
Periodical inspection
Even if any anomalies are not found during the daily inspections, your nearest
authorized Shimadzu service center should check the following items. It is
recommended to carry out the periodic check every 6 months.
Item Check point Remark
Support stand
(Column)
Check all fixing bolts and screws
Remove the
covers from the
root of the
column and the
arm.
Battery
1) Appearance?
2) Correct voltage?
The batteries are recommended to be replaced
every 2 years. Contact your nearest authorized
Shimadzu service center for the necessary
replacement. Replace batteries when a fully
charged set of batteries have a reduced operational
life.
Shimadzu part number 074-71031-02 20 pieces
Remove the
side cover.
Power supply Output voltage normal? Remove the side
cover.
X-ray output Check X-ray tube voltage and mAs. Remove the side
cover.
Wire rope
1) Any frayed or broken strands?
2) Is the fixing point normal?
3) Is the rope lubricated?
3) Any deformation or corrosion?*
The wire rope must be replaced at least every 10
years from the date of original equipment delivery.
Contact your nearest authorized Shimadzu service
center for the necessary replacement.
Shimadzu part number (2 pieces for 1 unit)
503-46520 for MUX-100D
503-46520-03 for MUX-100DJ
Remove the
covers from the
column and the
arm.
X-ray tube rotation Is the rotation lubricated?
Arm catch Check storage.
1) Are you fixed?
2) Any unusual looseness?
3) Confirmation of storage signal
To Next Page
