６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - １０
Rear view of the unit
(a) (b) (c)
Upper view of the unit
(d)
Fig. 6-14 Procedure of battery exchange
Fig. 6-15
Battery Wiring Disconnection Order
Fixing Plate
Link ASSY
BAT
2
1
6
BAT 1
7
8
BAT
4
4
5
BAT 3
2
3
