６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - １１
CAUTION The weight of the battery ASSY is approximately 16 kg ( 1 piece ). Pay rigid attention in
handling it.
Fig. 6-16 How to Take Out the Battery ASSY
(a) (b) (c)
Fig. 6-17 Battery ASSY
In battery set BAT1,BAT3 and BAT2,BAT4 is different of
structure.
The terminal block position , the battery position , and the
plate are different between these two types of assembly.
They are symmetrical.
Fig. 6-18 Battery ASSY
Battery
Terminal block
Box
Plate
