６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - １２
11. Insert new batteries, and connect the wires to the electrodes. Be careful that, as for
BAT2 and BAT4, their direction of battery is turned upside down.
12. Close the cover of the battery ASSY.
13. Write battery code and manufacture date of new battery in the label on top of battery
ASSY.
14. Mount the battery ASSY to the original position. Pay attention to the battery numbers
and positions. (Refer to Fig. 6-15.)
15. Connect the wires to the terminal block of battery ASSY in the reverse order of Fig.6-15.
(from No.8 to No.1)
Be sure to connect them in order first from (+) terminal of BAT 1 (Refer to Fig. 6-15).
16. Write the date of battery replacement in the Battery Replacement Label.
17. Mount the Link assy and connect the cables.
18. Mount the DR assy and fix it with Fix plates.
19. Mount the top cover and side cover.
20. Mount the FPD box.
21. Turn ON the main breaker, and turn ON the key switch.
