６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - ２４
Fig. 6-39 How to Remove the Wiring of Cord Reel
Xcont-2002
NEXSC CPU
MU-Driver-2
Breaker NFB1
Bus Extender
Remove the wiring o
f
cord reel from NFB1.
