learn how to set the default parameter, please refer to corresponding manual.
4.4.7 Memory Error E-08
When the alarm occurs, corresponding alarm indicator of control panel lights, LED
digital display area shows the fault code.
Try restarting to eliminate the fault, if you can not eliminate it, you need to replace
the controller.
4.4.8 Honeycomb-rotor Fault Alarm
When the alarm occurs, corresponding alarm indicator of control panel lights, LED
digital display area shows the fault code.
The fault indicates the rotating section or detection section is abnormal when the
honeycomb rotation.
4.4.9 Actual temperature exceeds EGO setpoint—Over-temperature alarm
E-10
E-04 and E-10 are the same alarm mechanism, but their tasks are different. They
monitor drying and heating regeneration process respectively. When the alarm
occurs, corresponding alarm indicator of control panel lights, LED digital display
area shows the fault code.
Please refer to 4.4.4.
4.4.10 Thermocouple Polarity False Alarm E-11
When the alarm occurs, corresponding alarm indicator of control panel lights, LED
digital display area shows the fault code.
In the controller above marked with thermocouple correct polarity, if positive and
negative pole is wrong, the fault occurs. You can adjust the polarity of the
thermocouple access to exclude alarm.
4.4.11 PID Self-tuning Wrong E-12
When the alarm occurs, corresponding alarm indicator of control panel lights, LED
digital display area shows the fault code.
The alarm does not occur when working properly. Only when the PID self-tuning
function is activated, unpredictable problems occur in the auto-tuning process, will
cause the fault. Now you can reboot and start PID auto-tuning, or manually enter
the PID parameters to exclude fault.
