Pressure settings for each model refer to the table below:
Pressure(bar)
Models
Low pressure High pressure
STM-PW 2 8
STM-HPW 2 13
STM-W 2 8
STM-WF 2 8
SIC-A-R2 4 37
SIC-A 2 25
SIC-W-R2 4 30
SIC-W 2 20
SICC-A-R2 4 37
SICC-A 2 25
SICC-W 2 20
Note:
1. If the controller labeled "AUTO RESET", the controller has an automatic reset
function; if the controller labeled “PRESS TO RESET”, the controller has a
manual reset function.
2. An example to illustrate the use of differential pressure adjustment screw (our
company does not use the function of screw)
Example: Pressure adjustment is 5bar, differential pressure adjustment is 1bar.
When the pressure drops to 5-1=4bar, pressure controller contacts switch;
when the pressure rises to 5bar, pressure controller contacts switch. How to
switch depends on the connection is normally open or normally closed
contacts.
