SICK C4000 Standard User Manual

Chapter 12 Operating Instructions
C4000 Standard/Advanced
106 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009861/WA65/2012-06-12
Subject to change without notice
Ordering information
12.4 C4000 Guest
12.4.1 C4000 Standard Guest with straight system connection
Part numbers for resolutionProtective field
height [mm]
14 mm 30 mm
150
 1028796
(C46S-0101CT400)
 1028797
(C46E-0101CT400)
 1028879
(C46S-0103CT400)
 1028880
(C46E-0103CT400)
300
 1028802
(C46S-0301CT400)
 1028803
(C46E-0301CT400)
 1028881
(C46S-0303CT400)
 1028882
(C46E-0303CT400)
450
 1028804
(C46S-0401CT400)
 1028805
(C46E-0401CT400)
 1028883
(C46S-0403CT400)
 1028884
(C46E-0403CT400)
600
 1028806
(C46S-0601CT400)
 1028807
(C46E-0601CT400)
 1028885
(C46S-0603CT400)
 1028886
(C46E-0603CT400)
750
 1028808
(C46S-0701CT400)
 1028809
(C46E-0701CT400)
 1028887
(C46S-0703CT400)
 1028888
(C46E-0703CT400)
900
 1040173
(C46S-0901CT400)
 1040174
(C46E-0901CT400)
 1040193
(C46S-0903CT400)
 1040194
(C46E-0903CT400)
1050
 1040175
(C46S-1001CT400)
 1040176
(C46E-1001CT400)
 1040195
(C46S-1003CT400)
 1040196
(C46E-1003CT400)
1200
 1040177
(C46S-1201CT400)
 1040178
(C46E-1201CT400)
 1040197
(C46S-1203CT400)
 1040198
(C46E-1203CT400)
1350
 1040179
(C46S-1301CT400)
 1040180
(C46E-1301CT400)
 1040199
(C46S-1303CT400)
 1040200
(C46E-1303CT400)
1500
 1040181
(C46S-1501CT400)
 1040214
(C46E-1501CT400)
 1040201
(C46S-1503CT400)
 1040202
(C46E-1503CT400)
1650
 1040182
(C46S-1601CT400)
 1040183
(C46E-1601CT400)
 1040203
(C46S-1603CT400)
 1040204
(C46E-1603CT400)
1800
 1040184
(C46S-1801CT400)
 1040185
(C46E-1801CT400)
 1040205
(C46S-1803CT400)
 1040206
(C46E-1803CT400)
Tab.
55
:
Part numbers
C4000 Standard Guest with
straight system connection

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
