About this document
We also refer you to the SICK homepage on the Internet at: www.sick.com
Here you will find information on:
sample applications
a list of frequently asked questions about the C4000
these operating instructions in different languages for viewing and printing
certificates on the prototype test, the EC declaration of conformity and other documents
1.5 Abbreviations
Application diagnostic output = configurable signal output that indicates a specific status
of the protective device
SICK Configuration & Diagnostic Software
External device monitoring
Enhanced function interface = safe SICK device communication
Electro-sensitive protective equipment (e.g. C4000)
Output signal switching device
1.6 Symbols used
Recommendations are designed to give you some assistance in your decision-making
process with respect to a certain function or a technical measure.
Refer to notes for special features of the device.
Display indicators show the status of the 7Csegment display of sender or receiver:
Constant indication of characters, e.g. U
Flashing indication of characters, e.g. 8
Alternating indication of characters, e.g. L and 2
The depiction of numbers on the 7Csegment display can be rotated by 180° with the aid of
the CDS. In this document the depiction of the numbers on the 7Csegment display is how-
ever always in the normal, non-rotated position.
LED symbols describe the state of a diagnostics LED. Examples:
Red The red LED is illuminated constantly.
Yellow The yellow LED is flashing.
Green The green LED is off.
Instructions for taking action are shown by an arrow. Read carefully and follow the instruc-
tions for action.
Warning!
A warning indicates an actual or potential risk or health hazard. They are designed to help
you to prevent accidents.
Read carefully and follow the warnings!
Note
ADO
CDS
EDM
EFI
ESPE
OSSD
Recommendation
Note
,
Red, Yellow,
Green
Take action …
