SICK C4000 Standard User Manual

Operating Instructions Chapter 11
C4000 Standard/Advanced
8009861/WA65/2012-06-12 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 77
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Operating data
S
ystem connection and extension
connection
H
irschmann plug M26× 11 + FE
Alternative extension connection Plug M12× 8 + FE
Cable length
19)
50 m
Wire cross-section 0.75 mm²
Bend radius 150 mm
Ambient operating temperature 0°C +55°C
Air humidity (non-dewing) 15%95%
Storage temperature –25°C +70°C
Housing cross-section 40 mm × 48 mm
Rigidity 5 g, 10-55 Hz (EN 60068C2C6)
Shock resistance 10 g, 16 ms (EN 60068C2C27)
11.2 Data sheet C4000 Guest
At variance with 11.1 “Data sheet” for the C4000 Guest the following data apply.
Minimum Typical Maximum
General system data
Protective field height, depending
on type
150 mm to 1800 mm
Resolution, depending on type 14 mm and 30 mm
Protective field width
Resolution 14 mm
0-8 m 0-10 m
20)
Resolution 30 mm 0-19 m 0-21 m
20)
 Sender unit
Weight
Depending on the protective field height (see
page 82)
19)
Depending on load, power supply and wire cross-section. The technical specifications must be observed.
20)
On the utilisation of this protective field width, it must be expected the orange LED will illuminate (cleaning or
realignment required). The system then only has a reserve of 30%.
Tab.
29
:
Data sheet
C4000
Guest

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
