SICK C4000 Standard User Manual

Chapter 11 Operating Instructions
C4000 Standard/Advanced
78 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009861/WA65/2012-06-12
Subject to change without notice
Technical specifications
Minimum Typical Maximum
 Receiver unit
O
utput signal switching devices
(OSSDs)
N
ot present
External device monitoring (EDM)
input
Not present
Control switch input (reset
button)
Not present
Output Reset required Not present
Application diagnostic output
(ADO)
Not present
Emergency stop/bypass Not present
Teach-in key-operated
switch/switch for deactivating the
blanking
Not present
Weight
Depending on the protective field height (see
page 82)
Operating data
Connection Cable plug M12× 7 + FE, 320 mm cable, maximum
extension to 3 m
Wire cross-section 0.25 mm²
Bend radius, rigid wiring 18 mm
Bend radius, flexible wiring 60 mm
Strain relief on the cable, static 90 N
Strain relief on the cable,
dynamic
35 N

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
