Ordering information
12.2.7 C4000 Standard without extension connection with pre@configuration F
The pre-configuration is a specific system delivery state (see chapter 8.1 “Default delivery
status” on page 66). You can change this configuration using the software supplied.
Part numbers for resolutionProtective field
height [mm]
14 mm 20 mm 30 mm 40 mm
300
 1018591
(C40S-0301CA010)
 1022490
(C40E-0301CF010)
 1018613
(C40S-0302CA010)
 1022501
(C40E-0302CF010)
 1018635
(C40S-0303CA010)
 1022512
(C40E-0303CF010)
 1018657
(C40S-0304CA010)
 1022523
(C40E-0304CF010)
450
 1018347
(C40S-0401CA010)
 1022491
(C40E-0401CF010)
 1018615
(C40S-0402CA010)
 1022502
(C40E-0402CF010)
 1018637
(C40S-0403CA010)
 1022513
(C40E-0403CF010)
 1018659
(C40S-0404CA010)
 1022524
(C40E-0404CF010)
600
 1018593
(C40S-0601CA010)
 1022492
(C40E-0601CF010)
 1018617
(C40S-0602CA010)
 1022503
(C40E-0602CF010)
 1018639
(C40S-0603CA010)
 1022514
(C40E-0603CF010)
 1018661
(C40S-0604CA010)
 1022525
(C40E-0604CF010)
750
 1018595
(C40S-0701CA010)
 1022493
(C40E-0701CF010)
 1018619
(C40S-0702CA010)
 1022504
(C40E-0702CF010)
 1018641
(C40S-0703CA010)
 1022515
(C40E-0703CF010)
 1018663
(C40S-0704CA010)
 1022526
(C40E-0704CF010)
900
 1018597
(C40S-0901CA010)
 1022494
(C40E-0901CF010)
 1018621
(C40S-0902CA010)
 1022505
(C40E-0902CF010)
 1018643
(C40S-0903CA010)
 1022516
(C40E-0903CF010)
 1018665
(C40S-0904CA010)
 1022527
(C40E-0904CF010)
1050
 1018599
(C40S-1001CA010)
 1022495
(C40E-1001CF010)
 1018623
(C40S-1002CA010)
 1022506
(C40E-1002CF010)
 1018645
(C40S-1003CA010)
 1022517
(C40E-1003CF010)
 1018667
(C40S-1004CA010)
 1022528
(C40E-1004CF010)
1200
 1018601
(C40S-1201CA010)
 1022496
(C40E-1201CF010)
 1018625
(C40S-1202CA010)
 1022507
(C40E-1202CF010)
 1018647
(C40S-1203CA010)
 1022518
(C40E-1203CF010)
 1018669
(C40S-1204CA010)
 1022529
(C40E-1204CF010)
1350
 1018603
(C40S-1301CA010)
 1022497
(C40E-1301CF010)
 1018627
(C40S-1302CA010)
 1022508
(C40E-1302CF010)
 1018649
(C40S-1303CA010)
 1022519
(C40E-1303CF010)
 1018671
(C40S-1304CA010)
 1022530
(C40E-1304CF010)
1500
 1018605
(C40S-1501CA010)
 1022498
(C40E-1501CF010)
 1018629
(C40S-1502CA010)
 1022509
(C40E-1502CF010)
 1018651
(C40S-1503CA010)
 1022520
(C40E-1503CF010)
 1018673
(C40S-1504CA010)
 1022531
(C40E-1504CF010)
1650
 1018607
(C40S-1601CA010)
 1022499
(C40E-1601CF010)
 1018631
(C40S-1602CA010)
 1022510
(C40E-1602CF010)
 1018653
(C40S-1603CA010)
 1022521
(C40E-1603CF010)
 1018675
(C40S-1604CA010)
 1022532
(C40E-1604CF010)
1800
 1018609
(C40S-1801CA010)
 1022500
(C40E-1801CF010)
 1018633
(C40S-1802CA010)
 1022511
(C40E-1802CF010)
 1018655
(C40S-1803CA010)
 1022522
(C40E-1803CF010)
 1018677
(C40S-1804CA010)
 1022533
(C40E-1804CF010)
Tab.
49
:
Part numbers
C4000 Standard without
extension connection with
pre;configuration F

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
