Ordering information
12.3.2 C4000 Advanced with M26 extension connection
Part numbers for resolutionProtective field
height [mm]
14 mm 20 mm 30 mm 40 mm
300
 1018690
(C40S-0301DA010)
 1018827
(C40E-0301DB010)
 1018710
(C40S-0302DA010)
 1018838
(C40E-0302DB010)
 1018733
(C40S-0303DA010)
 1018849
(C40E-0303DB010)
 1018755
(C40S-0304DA010)
 1018860
(C40E-0304DB010)
450
 1018349
(C40S-0401DA010)
 1018828
(C40E-0401DB010)
 1018712
(C40S-0402DA010)
 1018839
(C40E-0402DB010)
 1018735
(C40S-0403DA010)
 1018850
(C40E-0403DB010)
 1018757
(C40S-0404DA010)
 1018861
(C40E-0404DB010)
600
 1018692
(C40S-0601DA010)
 1018829
(C40E-0601DB010)
 1018714
(C40S-0602DA010)
 1018840
(C40E-0602DB010)
 1018737
(C40S-0603DA010)
 1018851
(C40E-0603DB010)
 1018759
(C40S-0604DA010)
 1018862
(C40E-0604DB010)
750
 1018694
(C40S-0701DA010)
 1018830
(C40E-0701DB010)
 1018716
(C40S-0702DA010)
 1018841
(C40E-0702DB010)
 1018739
(C40S-0703DA010)
 1018852
(C40E-0703DB010)
 1018762
(C40S-0704DA010)
 1018863
(C40E-0704DB010)
900
 1018696
(C40S-0901DA010)
 1018831
(C40E-0901DB010)
 1018718
(C40S-0902DA010)
 1018842
(C40E-0902DB010)
 1018741
(C40S-0903DA010)
 1018853
(C40E-0903DB010)
 1018765
(C40S-0904DA010)
 1018864
(C40E-0904DB010)
1050
 1018698
(C40S-1001DA010)
 1018832
(C40E-1001DB010)
 1018720
(C40S-1002DA010)
 1018843
(C40E-1002DB010)
 1018743
(C40S-1003DA010)
 1018854
(C40E-1003DB010)
 1018767
(C40S-1004DA010)
 1018865
(C40E-1004DB010)
1200
 1018700
(C40S-1201DA010)
 1018833
(C40E-1201DB010)
 1018722
(C40S-1202DA010)
 1018844
(C40E-1202DB010)
 1018745
(C40S-1203DA010)
 1018855
(C40E-1203DB010)
 1018769
(C40S-1204DA010)
 1018866
(C40E-1204DB010)
1350
 1018702
(C40S-1301DA010)
 1018834
(C40E-1301DB010)
 1018724
(C40S-1302DA010)
 1018845
(C40E-1302DB010)
 1018747
(C40S-1303DA010)
 1018856
(C40E-1303DB010)
 1018771
(C40S-1304DA010)
 1018867
(C40E-1304DB010)
1500
 1018704
(C40S-1501DA010)
 1018835
(C40E-1501DB010)
 1018726
(C40S-1502DA010)
 1018846
(C40E-1502DB010)
 1018749
(C40S-1503DA010)
 1018857
(C40E-1503DB010)
 1018773
(C40S-1504DA010)
 1018868
(C40E-1504DB010)
1650
 1018706
(C40S-1601DA010)
 1018836
(C40E-1601DB010)
 1018728
(C40S-1602DA010)
 1018847
(C40E-1602DB010)
 1018751
(C40S-1603DA010)
 1018858
(C40E-1603DB010)
 1018775
(C40S-1604DA010)
 1018869
(C40E-1604DB010)
1800
 1018708
(C40S-1801DA010)
 1018837
(C40E-1801DB010)
 1018730
(C40S-1802DA010)
 1018848
(C40E-1802DB010)
 1018753
(C40S-1803DA010)
 1018859
(C40E-1803DB010)
 1018777
(C40S-1804DA010)
 1018870
(C40E-1804DB010)
Tab.
52
:
P
art numbers
C4000 Advanced with M26
extension connection

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
