12.6.2 Deflector mirror PNS125 for protective field width 4 … 18.5 m (total)
Protective field height [mm] Type code Part number
300 PNS125-034 1019425
450 PNS125-049 1019426
600 PNS125-064 1019427
750 PNS125-079 1019428
900 PNS125-094 1019429
1050 PNS125-109 1019430
1200 PNS125-124 1019431
1350 PNS125-139 1019432
1500 PNS125-154 1019433
1650 PNS125-169 1019434
1800 PNS125-184 1019435
Dimensional drawing see Fig. 53 on page 92. Effect on the scanning range see Tab. 8 on
page 27.
12.7 Accessories
Part Part number
C4000-system connection
Hirschmann cable socket M26×11 + FE, crimp contacts, straight 6020757
Hirschmann cable socket M26×11 + FE, crimp contacts, angled 6020758
Terminal with 182  resistance for pin 9 and 10 on the system
connection (cf. page 53)
2027227
Connection cable
21)
Socket straight/stripped, 2.5 m 2022544
Socket straight/stripped, 5 m 2022545
Socket straight/stripped, 7.5 m 2022546
Socket straight/stripped, 10 m 2022547
Socket straight/stripped, 15 m 2022548
Socket straight/stripped, 20 m 2022549
Socket straight/stripped, 30 m 2022550
21)
The cable sheath is made of PVC (UL listed).
Tab.
61
:
Part numbers
deflector mirror PNS125
Tab.
62
:
Part numbers
accessories

SICK C4000 Standard Specifications

General

Type	Safety Light Curtain
Number of Beams	Varies with protective field height and resolution
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65, IP67
Type IEC	Type 4
Category	Category 4
Protective Field Height	300 mm to 1800 mm
Supply Voltage	24 V DC
Connection	M12 connector
Outputs	PNP
Resolution	14 mm, 30 mm
Operating Temperature	-25 °C ... +55 °C
