Operating Instructions Chapter 4
C4000 Standard/Advanced
8009861/WA65/2012-06-12 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 39
Subject to change without notice
Configurable functions
4.11 Functions that cannot be combined
Function that can be
configured
Limitation
Teach-in key-operated
switch on the M26
extension connection
Emergency stop function or Bypass can only be used in
conjunction with a SICK switching amplifier (teach-in on
the switching amplifier, emergency stop/bypass on the
C4000)
Emergency stop on the
M26 extension
connection
Teach-in or Bypass only possible in conjunction with SICK
switching amplifier. It is possible to connect either an
emergency stop signal, a key-operated pushbutton for
bypass or a teach-in key-operated switch
Bypass on the M26
extension connection
The Emergency stop or the Teach-in function can only be
used in conjunction with a SICK switching amplifier (teach-
in on the switching amplifier, emergency stop on the
C4000)
Reduced resolution Not with floating blanking with partial object monitoring
Not with fixed blanking and increased size tolerance
Floating blanking with
partial object monitoring
Not with floating blanking with partial object monitoring
Cannot be used if a neighbouring area uses floating
blanking with complete object monitoring
Not with fixed blanking and increased size tolerance
Not with reduced resolution
Floating blanking with
complete object
monitoring
Cannot be used if a neighbouring area uses floating
blanking with partial object monitoring
Not with fixed blanking with increased size tolerance
Fixed blanking with
increased size tolerance
Not with floating blanking with partial object monitoring
Not with floating blanking with complete object monitoring
Not with reduced resolution
cannot be combined
