Position Description Characteristic
6 Scanning method, reading
window orientation
1)
0: Line scanner, reading window on front
1: Raster scanner, reading window on front
2: Line scanner, reading window on side
3: Raster scanner, reading window on side
7 Electrical connections
(design)
0: Cable 0.9 m with male connector, D-Sub-HD,
15-pin
4: Swivel connector, 2 x female connectors, M12,
4-pin, D-coded +1 x cable 0.9 m with male connec‐
tor, M12, 4-pin, A-coded
5: Swivel connector, 2 x female connectors, M12,
4-pin, D-coded +1 x cable 0.9 m with male connec‐
tor, M12, 5-pin, A-coded
8 Interfaces 0: Host (RS-232), AUX (RS-232), digital I/Os
1)
1: Host (Ethernet), AUX (Ethernet, USB
2)
)
2: Host (Ethernet), AUX (Ethernet, USB
2)
), 1 x digital
switching input
3: Host (Ethernet), AUX (Ethernet), 1 x external para‐
meter storage (microSD memory card)
3)
4: Host (Ethernet), AUX (Ethernet), 1 x external para‐
meter storage (microSD memory card)
3)
, 1 x digital
switching input
9 Front screen material 0: Glass
1: Plastic
10 Application (ambient tem‐
perature)
Without label: Standard (0 °C ... +40 °C)
F0: With integrated heating (‒35 °C ... +40 °C)
1)
2 x digital switching inputs and 2 x digital switching outputs.
2)
USB interface only for temporary use as a service interface.
3)
For service functions such as parameter cloning.
NOTE
Not all combinations are possible according to the type code. The available device vari‐
ants can be found online at:
•
www.sick.com/CLV61x_Dual_Port
3.1.3 Device variants
The CLV61x product family consists of 3 variant lines:
•
CLV61x CAN
•
CLV61x FIELDBUS (in combination with the optional fieldbus module CDF600)
•
CLV61x Dual Port
Among other things, the variant lines differ with respect to the following features:
Table 3: Differences between the variant lines
Feature CLV61x CAN CLV61x FIELDBUS CLV61x Dual Port
(PROFINET)
Purpose Data output to host via
RS-232
Connection to fieldbus
via optional fieldbus
module CDF600
(Dual Port switch)
Direct integration in
line or ring topology
