SICK CLV61 DualPort Series - Page 15

Feature CLV61x CAN CLV61x FIELDBUS CLV61x Dual Port
(PROFINET)
Electrical Interfaces
•
Power
•
RS-232
(Host, AUX)
•
CAN
•
2 digital switching
inputs
•
2 digital switching
outputs
•
Power
•
RS-232
(Host, AUX)
•
CAN
•
2 digital switching
inputs
•
2 digital switching
outputs
•
Power
•
Ethernet
(Host, AUX)
•
USB Micro-B or
microSD memory card
1) 2) 5)
•
1 digital switching
input
1)
Type of electrical
connections
1 x male connector, D-Sub-HD, 15-pin 2 x female connectors,
M12, 4-pin, D-coded in
swivel connector
1 x male connector, 4-
or 5-pin, A-coded
1)
1 x female connector,
5-pin, USB Micro-B type
or
microSD memory card
1)
Supply voltage DC 10 V ... 30 V DC 10 ... 30 V
DC 18 ... 30 V
3)
Power consumption Typically 2.8 W
4)
Typically 4 W
4)
Typically 15 W
3) 4)
Special evaluation
feature
SMART620 decoder
Memory card – Optional
1) 5)
Heating – Optional
1)
Ambient operating
temperature
0 °C ... +40 °C 0 °C ... +40 °C
–35 °C ... +40 °C
1) 3)
Storage tempera‐
ture
–20 °C ... +70 °C –20 °C ... +70 °C
–35 °C ... +70 °C
1) 3)
Dimensions for
device with front
reading window
61 mm x 66 mm x 38 mm 61 mm x 96 mm x
38 mm
Dimensions for
device with side
reading window
80 mm x 66 mm x 38 mm 80 mm x 96 mm x
38 mm
1)
Depending on type.
2)
USB interface only for temporary use as a service interface.
3)
For device variants with integrated heating.
4)
For switching outputs without load.
5)
USB interface or memory card shaft.
Designation of device variants
•
Device variants with serial data interfaces only (RS-232, RS422/485) are referred
to as “serial variants”. They also feature a CAN interface. The connecting cable
with a D-Sub male connector is permanently connected to the housing.
•
Device variants with serial data interfaces and two additional Ethernet interfaces
are referred to as “Dual Port variants”. They feature a swivel connector on the
housing with two M12 female connectors and a separate connecting cable with an
M12 male connector.
•
The corresponding number of digital switching inputs and outputs depends on the
design of the electrical connection.
