SICK MARSIC200 User Manual

7.2 Gas flow diagram
SINGLE version distribution unit for one measuring point
-HQ1
0,1 µm
OUT IN
-EB2
120 °C
-EB1
COND
IN OUT
-EC1
+UM1/4.6
A R
-KK10
+UM5/8.2
C/T
P
OPTION
Reference gas CO2/SO2/O2
and/or N2 for O2 zero,
manual application
Test gas
Zero gas
! Note backpressure ! reed manual for details.
Instrument air
Reference gas manual
-QN1
[max.0,5 bar(ü)]
HP LP
OUT
IN
-BQ1
SO2 CO2 O2 (NO) (NO2)
-GQ1
+UM5/7.4
E A
-RM1
cracking pressure
0,2 bar
-PG1
10...100 Nl/h
(60 Nl/h)
flow meter
-HS1
acid absorber
filling cotton
R A
-KK1
+BQ1/6.5
C/T
P
OUT
KOND
-01
-XL9
-XL10
-XL50
+UM1
+UM5
+STACK
-XL1
-XL10
-XL2
Referenzgas manual
-QN1
[max.0,5 bar(ü)]
HP LP
rd
bu
rd
bu
Figure 36: Gas flow diagram
TECHNICAL DATA
7
8017324/15A2/V6-0/2019-10 | SICK T E C H N I C A L I N F O R M A T I O N | MARSIC200
59
Subject to change without notice
