SICK MARSIC200 User Manual

Ambient conditions in storage
Ambient temperature -20 ... +70 °C
Relative humidity < 90% (without condensate)
7.5 Sample gas conditions
Sample gas at the measuring point Characteristics
Process temperature 10 ... 550 °C
Sample gas temperature 200°C
Process pressure –90 ... +200 hPa relative
Dust load < 200 mg/m
3
7.6 Design as wall enclosure
Sampling probe
Ambient temperature -25 ... 65 °C
Working temperature +180 °C, self-regulating
Filter element Fine filter 0.1 µm
Power supply 115 V / 230 V
Power consumption Start: 400 VA, operation: 100 VA
Degree of protection IP 54
Weight Approx. 7.5 kg
Dimensions see "Dimensional drawing of sampling probe", page 58
Design as wall enclosure
Design 3 x wall enclosure
•
Sample conditioning
•
Distribution unit
•
Analyzer
Material, general Steel plate according to EN 10130
Dimensions see "Dimensional drawings", page 55
Installation Wall fitting
Weight
•
Sample conditioning: Approx. 27 kg
•
Distribution unit: Approx. 30 kg
•
Analyzer: Approx. 37 kg
Materials with media contact
•
PTFE
•
Viton B
•
PVDF
•
Stainless steel 1.4571
•
Platinum, nickel
•
Aluminum
•
CaF
2
Degree of protection
•
Sample conditioning: IP54
•
Distribution unit: IP54
•
Analyzer: IP54
7 TECHNICAL DATA
62
T E C H N I C A L I N F O R M A T I O N | MARSIC200 8017324/15A2/V6-0/2019-10 | SICK
Subject to change without notice
