4 Transport and storage
4.1 Transport
Overview
Transport and install the device with suitable hoisting equipment (e.g. a crane or jack
lift with adequate lifting capacity).
Important information
NOTICE
The measuring device may only be transported and installed by qualified persons who,
based on their training and knowledge as well as knowledge of the relevant regulations,
can assess the tasks given and recognize the dangers involved.
Transport via crane
Analyzer cabinets are transported safely with delivered lifting lugs. The following permis‐
sible total loads apply for symmetrical loads:
•
For 45° cable pull angle 4 800 N
•
For 60° cable pull angle 6 400 N
•
For 90° cable pull angle 13 600 N
4 TRANSPORT AND STORAGE
20
