13.2.3 Housing
Table 15: Design
Design
Design 1 x stand-alone enclosure
Material, general Steel plate, aluminium cast
Dimensions see "", page 60
Installation Upright
Weight Approx. 200 kg
Materials with media contact
•
Stainless steel 1.4571
•
PTFE
•
Aluminium (coated)
Degree of protection IP 54
Impact resistance IK08
13.2.4 Interfaces and protocols
Table 16: Interfaces and protocols
Operation and interfaces
Operation Via display or Google Chrome browser with SOPASair
software, several operating levels, password-protected
Display and input Foiled color display with touchscreen
Analog inputs/outputs Optional
Digital inputs/outputs Optional
Data interface 1 x Modbus TCP/IP
Profibus Configurable
Profinet Configurable
Remote support SICK MPR (optional)
PC operation Browser Google Chrome with SOPASair via Ethernet
13.2.5 Power supply
Table 17: Voltage supply
Voltage supply
Power input
•
Analyzer
•
Heated sample gas line
•
Gas sampling unit
•
Heated probe tube
Power input
•
Approx. 1000 VA
•
Approx. 95 VA/m
•
Approx. 450 VA
•
Approx. 450 VA
Table 18: Optional interfaces
Interfaces (optional)
Digital outputs 4 outputs, 24 V, 0.5 A
Digital inputs Electrically isolated, 24 V, 0.3 A
Table 19: Cable glands
Cable glands
Hose bundle line M40x1.5 D22 -32 IP68 PA-GR
Main power supply M32x1.5 D18 -25 IP68 PA-GR
UPS power supply M20x1.5 D10 -14 IP68 PA-GR
13 TECHNICAL DATA
64
O P E R A T I N G I N S T R U C T I O N S | MCS200HW 8021889/1D1T/V3-1/2021-09 | SICK
Subject to change without notice
