SICK MCS200HW User Manual

ELECTRONIC FILTERTUBE 1 FILTER
PROBE 2PROBE 1
TUBE 2 TUBE 3 CELL DEVICE
Fuse connections
Name Fuse for
ELECTRONIC Electronics
TUBE 1 Sample gas line 1
FILTER/PROBE 1 Filter heater / measuring probe 1
TUBE 2 Sample gas line 2
FILTER/PROBE 2 Filter heater / measuring probe 2
TUBE 3 Sample gas line 3
CELL Sample gas cell
DEVICE Device
13.2.9.3 Connections for heated components
Overview
TUBE 1 FILTER 1 PROBE 1 FILTER 2 PROBE 2TUBE 2 TUBE 3
TECHNICAL DATA 13
8021889/1D1T/V3-1/2021-09 | SICK O P E R A T I N G I N S T R U C T I O N S | MCS200HW
67
Subject to change without notice
