5 Mounting
5.1 Safety
Qualification
The measuring device may only be installed by trained specialists.
5.2 Scope of delivery
Please see the delivery documents for the scope of delivery.
5.3 Overview of mechanical and electrical installation
Important information
NOTICE
Observe the order of assembly.
If the assembly sequence is incorrect, there is a risk of contamination of the gas sam‐
pling unit. This can cause exhaust gas to enter the unheated analyzer and condense
out.
b
First connect instrument air and voltage supply.
b
Only then install the gas sampling unit in the flue gas duct.
Installation sequence
•
Install analyzer cabinet
•
Electrical connections on analyzer
•
Connect signal lines to analyzer
•
Install SFU gas sampling system
•
Connect heater hose
•
Air and gas connections on analyzer
•
Connect sample gas line to analyzer
•
Sample gas outlet
5 MOUNTING
22
O P E R A T I N G I N S T R U C T I O N S | MCS200HW 8021889/1D1T/V3-1/2021-09 | SICK
Subject to change without notice
