SICK MCS200HW User Manual

Torques
Table 32: Torques
Dimension Slope P Tightening torque M
A
(Nm) according to strength class (see screw
head)
3.6 4.6
A2-50
A4-50
5.6
Alu
A2-70
A4-70
A2-80
A4-80
8.8
Titan
10.9 12.9
M 1.6 0.4 0.05 0.05 0.05 0.11 0.16 0.19 0.26 0.31
M 2 0.45 0.1 0.1 0.11 0.22 0.32 0.39 0.55 0.66
M 2.5 0.45 0.21 0.22 0.23 0.46 0.67 0.81 1.13 1.36
M 3 0.5 0.54 1 1.2 1.39 1.51 1.98 2.37
M 3.5 0.6 0.85 1.3 1.54 1.75 1.9 2.6 3.2
M 4 0.7 1.02 2 2.5 3 3.3 4.8 5.6
M 5 0.8 2 2.7 4.2 5.6 6.5 9.5 11.2
M 6 1 3.5 4.6 7.3 9.7 11.3 16.5 19.3
M 8 1.25 8.4 11 17,5 23.3 27.3 40.1 46.9
M 10 1.5 17 22 35 47 54 79 93
M 12 1.75 29 39 60 79 93 137 160
M 14 2 46 62 94 126 148 218 255
M 16 2 71 95 144 192 230 338 395
M 18 2.5 97 130 199 266 329 469 549
M 20 2.5 138 184 281 374 464 661 773
M 22 2.5 186 250 376 508 634 904 1057
M 24 3 235 315 485 645 798 1136 1329
M 27 3 350 470 708 947 1176 1674 1959
M 30 3.5 475 635 969 1289 1597 2274 2662
M 33 3.5 645 865 1319 1746 2161 3078 3601
M 36 4 1080 1440 1908 2350 2778 3957 4631
M 39 4 1330 1780 2416 3016 3597 5123 5994
13 TECHNICAL DATA
72
O P E R A T I N G I N S T R U C T I O N S | MCS200HW 8021889/1D1T/V3-1/2021-09 | SICK
Subject to change without notice
