Code Error message Error reaction Possible reason
E35
(0x523)
(1315
d
)
Error in external power supply unit
Drive is immediately disabled,
motor coasts to standstill.
▶ Error message from external power
supply unit; power supply is
switched off.
E36
(0x524)
(1316
d
)
Encoder 0 monitoring
Motor is stopped by current moni‐
toring via short-circuit of the motor
phases.
▶ Connection of encoder 0 is faulty
▶ Broken cable
E37
(0x525)
(1317
d
)
Ballast circuit load (I²t ballast
resistor)
Drive is immediately disabled,
motor coasts to standstill.
Ballast circuit load due to:
1 I²t 1 Wrong dimensioning, too much
energy supplied to R
Ballast
, broken
cable, no bridge at R
Ballast
(int./
ext.)
2
(VCE) desaturation detection
or: DC DC converter over‐
load
(only 0362144xy)
2
Bridge at R
Ballast
is not correct,
short circuit of insulation etc.
Or: internal hardware fault
(only
0362144xy)
E37
(0x525)
(1317
d
)
DC DC converter overload
(only
0362161xy)
Power supply unit will be discon‐
nected from mains.
▶ Overload at voltage converter of
DC link
E38
(0x526)
(1318
d
)
Actual speed value greater than
overspeed threshold
Motor is stopped by current moni‐
toring via short-circuit of the motor
phases.
(1)
▶ Wrong parameters
▶ Motor connected incorrectly
E39
(0x527)
(1319
d
)
Tracking error monitoring and
motor slowdown
Motor is stopped by current moni‐
toring via short-circuit of the motor
phases.
(1)
▶ Wrong parameters
▶ Motor connected incorrectly
▶ Mechanical problems
E40
(0x528)
(1320
d
)
Motor feedback
Motor is stopped by current moni‐
toring via short-circuit of the motor
phases.
(1)
▶ Connection of motor feedback
faulty
▶ Broken cable
E41
(0x529)
(1321
d
)
Motor phase lost
Motor is stopped by current moni‐
toring via short-circuit of the motor
phases.
(1)
Motor connection/configuration is faulty:
1 No motor connected 1 No motor connected / incorrect
wiring, broken cable
2 Wrong motor connected 2 Wrong parameters
E42
(0x52A)
(1322
d
)
Overvoltage in DC link
Drive is immediately disabled,
motor coasts to standstill.
▶ No ballast resistor is connected or
ballast resistor is dimensioned too
small, i.e. X41/X63 not connected
E43
(0x52B)
(1323
d
)
Undervoltage in DC link
Drive is immediately disabled,
motor coasts to standstill.
▶ DC link not connected
E44
(0x52C)
(1324
d
)
Commutation lost
The following list of error
messages includes a note for
which drive function the error
might appear.
▶
1
HSBLOCK
▶
2
FPAM
▶
3
SVC
▶
4
HSPWM
▶
5
VF
Drive is immediately disabled,
motor coasts to standstill.
The error E44 is triggered in case of
wrong current feed of the motor during
operation without sensor.
Possible reason: wrong parameter
setting or overload of the motor. The
error depends on the drive function. For
details refer to the corresponding setup
instructions.
1
EMF monitoring
1, 2, 3 4
2
Flux monitoring
4
3
Over current monitoring
4
Status Display and Error Messages
W
62 Drive Amplifier SD2B / SD2B plus - Hardware Description
