S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
9-3
5HFRPPHQGHGSURFHGXUH3DUW,,6RIWZDUH
Table 9-2 Recommended commissioning procedure - part II: software
7DVNV 5HPDUNV ,QIRUPDWLRQFDQEH
IRXQGLQ
• Switch on the PG
and start SIMATIC
Manager
• Download the
configuration and the
program to the CPU
- in the 67(3
Programming Manual
Testing the I/O Helpful functions are here:
• Monitoring and modifying of variables
• Testing with program status
• Force
• Modifying outputs in STOP mode (PO enable)
7LS Test the signals at the inputs and outputs
using the simulation module SM 374, for
example.
• in the 67(3
Programming Manual
• in Chapter 7HVWLQJ
)XQFWLRQV'LDJQRVWLFV
DQG)DXOW(OLPLQDWLRQ
Commission PROFIBUS
DP or other networks
- in Chapter &RPPLVVLRQLQJ
352),%86'3
Connect the outputs Commissioning the outputs successively. -
'DQJHU
Proceed step-by-step. Do not go to the next step unless you have completed the
previous one without error/error message.
5HVSRQVHWRHUURUV
React to errors as follows:
• Check the system with the help of the Checklist in the chapter below.
• Check the LED displays on all modules. Notes on their significance can be
found in the chapters describing the relevant modules.
• If required, remove individual components to trace the error.
,PSRUWDQWQRWHVDUHDOVRIRXQG
in Chapter 7HVWLQJ)XQFWLRQVGLDJQRVWLFVDQGIDXOWHOLPLQDWLRQ
VHHDOVR
Commissioning Checklist

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
