S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-4 A5E00105492-03
 &RPSRQHQW'LPHQVLRQV
/HQJWKRIWKHUDLOV
The following rails are available.
Table 5-1 Rails - overview
5DLOOHQJWK 8VDEOHOHQJWKIRUPRGXOHV 2UGHU1R
160 mm 120 mm ES7 390-1AB60-0AA0
482.6 mm 450 mm ES7 390-1AE80-0AA0
530 mm 480 mm ES7 390-1AF30-0AA0
830 mm 780 mm ES7 390-1AJ30-0AA0
2,000 mm cut to length if required ES7 390-1BC00-0AA0
In contrast to other rails, the 2-meter rail is not equipped with any fixing holes.
These must be drilled, allowing optimal adaptation of the 2-meter rail to your
application.
,QVWDOODWLRQGLPHQVLRQVRIPRGXOHV
Table 5-2 Module width
0RGXOH :LGWK
Power supply PS 307, 2 A 50 mm
Power supply PS 307, 5 A 80 mm
Power supply PS 307, 10 A 200 mm
CPU The installation dimensions are listed in
the Technical Data section of your &38
'DWD5HIHUHQFH0DQXDO.
Analog I/O modules 40 mm
Digital I/O modules 40 mm
Simulator module SM 374 40 mm
Interface modules IM 360 and IM 365 40 mm
Interface module IM 361 80 mm
• Module height: 125 mm
• Module height with VKLHOGLQJFRQWDFWHOHPHQW: 185 mm
• Maximum mounting depth: 130 mm
• Maximum mounting depth of a CPU with an inserted DP connector with angled
cable outlet: 140 mm
• Maximum mounting depth with open hinged front panel (CPU): 180 mm
Dimensions of other modules such as CPs, FMs etc. are found in the relevant
manuals.

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
