&RPPLVVLRQLQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
9-4 A5E00105492-03
&RPPLVVLRQLQJ&KHFNOLVW
,QWURGXFWLRQ
After you have mounted and wired your S7-300, we recommend you check all
previous steps once again.
The checklist tables below are a guide for your examination of the S7-300. They
also provide cross-references to chapters containing further information on the
relevant topic.
0RGXOHUDFNV
3RLQWVWREH([DPLQHG 6+DUGZDUHDQG
,QVWDOODWLRQ&KDSWHUV
Are the rails mounted firmly to the wall, in the frame or in
the cabinet?
Configuring, Installation
Have you maintained free space required? Configuring, Installation
Are the cable ducts installed properly? Configuring
Is the air convection OK? Installation
&RQFHSWRIJURXQGLQJDQGFKDVVLVJURXQG
3RLQWVWREH([DPLQHG 6+DUGZDUHDQG
,QVWDOODWLRQ&KDSWHUV
Have you established a low-impedance connection
(large surface, large contact area) to local ground?
Configuring, Appendix
Are all racks (rails) properly connected to reference
potential and local ground (electrical connection or
isolated operation)?
Configuring, Wiring, Appendix
Are all grounding points of electrically connected
modules and of the load power supply units connected
to reference potential ?
Configuring, Appendix
0RGXOHLQVWDOODWLRQDQGZLULQJ
3RLQWVWREH([DPLQHG 6+DUGZDUHDQG
,QVWDOODWLRQ&KDSWHUV
Are all modules properly inserted and screwed in? Installation
Are all front connectors properly wired, plugged, screw-
tightened or latched to the correct module?
Installation, Wiring
