Siemens CPU 313C Hardware And Installation Guide

&RQILJXULQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
5-33
03,352),%86'3DGGUHVVHV
To ensure that all nodes can intercommunicate, you must assign them an address:
• In the MPI network: an “MPI address“
• In the PROFIBUS DP network: a “PROFIBUS DP address“
On the PG you can specify individual MPI/PROFIBUS addresses for each one of
the nodes (on some of the PROFIBUS DP slaves this is also possible per selector
switch).
'HIDXOW03,352),%86'3DGGUHVVHV
The table below shows you the factory setting of the MPI/PROFIBUS DP
addresses and the highest default MPI/PROFIBUS DP addresses for the devices.
Table 5-14 MPI/PROFIBUS DP addresses
1RGH
GHYLFH
'HIDXOW
03,352),%86
'3DGGUHVV
'HIDXOWKLJKHVW03,
DGGUHVV
'HIDXOWKLJKHVW
352),%86'3DGGUHVV
PG 0 32 126
OP 1 32 126
CPU 2 32 126
5XOHV$VVLJQLQJ03,352),%86'3DGGUHVVHV
Note the following rules before assigning MPI/PROFIBUS addresses:
• All MPI/PROFIBUS addresses in a subnet must be unique.
• The highest MPI/PROFIBUS address must be ≥ of the physical
MPI/PROFIBUS address, and it must be identical for each node. (Exception:
Connecting a PG to multiple nodes; refer to the next Chapter).

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
