Siemens CPU 313C Hardware And Installation Guide

&RQILJXULQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-44 A5E00105492-03
([DPSOH0D[LPXPGLVWDQFHVLQWKH03,VXEQHW
The figure below shows you:
• a possible MPI Subnet configuration
• maximum distances possible in an MPI subnet
• the principle of “Line extension“ using RS485 repeaters
max. 50 m
max. 50 m
PG
PG
RS 485-
Repeater
max. 1000 m
3
S7-300
CPU
PS
CPU
MPI addr. 3
3
S7-300
CPU
PS
CPU
MPI addr. 5
3
S7-300
CPU
PS
CPU
MPI addr. 6
MPI addr. 4
OP 27
MPI addr. 7
3
S7-300
CPU
PS
CPU
MPI addr. 8
RS 485-
Repeater
MPI addr. 9
OP 27
3
S7-300
CPU
PS
CPU
MPI addr. 10
MPI addr. 11
OP 27
MPI addr. 0
1
1
1
1
1
1
2
Figure 5-15 Example: Maximum distances in the MPI subnet
.H\WRQXPEHUVLQWKHILJXUH
 Terminating resistor inserted
 PG connected by means of a stub cable for maintenance purposes


Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
