7HVWLQJ)XQFWLRQV'LDJQRVWLFVDQG)DXOW(OLPLQDWLRQ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
11-20 A5E00105492-03
(YHQWUHFRJQLWLRQ
The table below shows how CPU 31x-2 operating as DP slave recognized
operating state transitions or data exchange interruptions.
Table 11-11 Event recognition by CPUs 31x-2 acting as the DP slave
(YHQW :KDWKDSSHQVLQWKH'3VODYH"
Bus failure interrupt (short-
circuit, connector unplugged)
• Calls OB86 with the message 6WDWLRQIDLOXUH(incoming
event; diagnostic address of the DP slave, assigned to
the DP slave)
• with I/O access: Call of OB122 (I/O access error)
DP master: RUN → STOP • Calls OB82 with the message 0RGXOHHUURU(incoming
event; diagnostic address of the DP slave assigned to
the DP slave; Variable OB82_MDL_STOP=1)
DP master: STOP → RUN • Call of OB82 with the message 0RGXOH2.(outgoing
event; diagnostic address of the DP slave, assigned to
the DP slave; Variable OB82_MDL_STOP=0)
(YDOXDWLRQLQWKHXVHUSURJUDP
The table below shows you how you can, for example, evaluate RUN-STOP
transitions of the DP master in the DP slave (see also the previous table).
Table 11-12 Evaluation of RUN to STOP transitions in the DP master/DP slave
,QWKH'3PDVWHU ,QWKH'3VODYH
Diagnostic addresses: (Example)
Master diagnostic address =
Slave diagnostic address in the master
system=
(Slot 0 of slave)
(Diagnostic) address for "Slot 2"=
(Slot 2 of slave)
Diagnostic addresses: (Example)
Slave diagnostic address =
Master diagnostic address = irrelevant
CPU: RUN " STOP → The CPU calls OB82 with the following
information:
• OB82_MDL_ADDR:=422
• OB82_EV_CLASS:=B#16#39 (incoming
event)
• OB82_MDL_DEFECT: = Module error
Tip: The CPU diagnostic buffer also
contains this information
